Features

• 12-inch Woofer; 1.75-inch diaphragm compression driver
• 75° conical DMT™ coverage
• Maximum SPL 131 dB peak
• Also functions as monitor floor wedge
• 1000-watt Class D power modules in all models (2 × 500 W continuous)
• Onboard mixer with two combo XLR and ¼⁻ᶦⁿᶜʰ inputs, and stereo RCA inputs, (three audio input sources); two direct channel outputs and single summed balanced output

• Extensive DSP featuring DEEP™ and Intrinsic Correction™ enhances system performance
• Directivity Matched Transition^® (DMT) ensures uniform coverage across the entire sound field
• Rugged, texture-painted birch enclosures
• Four-position Mic/Line gain (full-range models)
• Tour-grade 16 gauge steel grilles
• Comfortable ergonomic handles
• 35 mm pole sockets with Tilt-Direct™
• M10 rigging points for suspended installation
