- Q-SYS Control plugin enables integration existing Q-SYS PA Router functionality in Q-SYS Designer Software
- Bi-color (red/green) Ready, Busy, and Zone Status LEDs can indicate zone and system status, driven by the PMS controller
- Convenient rear panel switch allows the use of either dynamic or phantom powered paging microphones
- Zip4-3G (3-Gang US) allows the use of a gooseneck (with or without an integrated PTT switch) for either desktop or wall mount applications
- PoE capable (802.3af)
System Details | |
Zone buttons | Four, white backlit, each with an associated bicolor status LED. LED state is fully controlled over the network, and button state can be monitored over the network. |
Ready and busy | Bi-color Ready and Busy system status LEDs. LED state is full controlled over the network |
Microphone/PTT input | XLR input, RJ-45 and side-mounted 6-pin depluggable. PTT input is dry contact, closed is active |
Microphone gain | +25 dB (with automatic phantom power) and +35 dB |
Power over Ethernet | 802.3af PoE PD compliant |
Dimensions (HWD) | 4.5 x 6.4 x 2 in (114.3 x 162.6 x 43.2 mm) |
