- Very low-profile design for minimum visibility
- Wide-range condenser element with low-mass diaphragm for superior performance
- Uniform polar pattern for maximum rejection of unwanted sounds
- Rugged design and construction
- 25' (7.6 m) cable permanently attached between microphone and XLRM-type connector
Specifications
| Microphones | |
|---|---|
| Element | Fixed-charge back plate, permanently polarized condenser |
| Polar Pattern | Half-cardioid (cardioid in hemisphere above mounting surface) |
| Frequency Response | 70-14,000 Hz |
| Open Circuit Sensitivity | -38 dB (12.5 mV) re 1V at 1 Pa |
| Maximum Input Sound Level | 134 dB SPL, 1 kHz at 1% T.H.D. |
| Dynamic Range | 105 dB, 1 kHz at Max SPL |
| Signal-to-Noise Ratio | 65 dB, 1 kHz at 1 Pa |
| Phantom Power Requirements | 9-52V DC, 2 mA typical |
| Weight | 1.2 oz (35 g) |
| Cable | 25' (7.6 m) long, permanently attached |
| Dimensions | 1.44" (36.6 mm) maximum width, 2.14" (54.3 mm) maximum length, 0.61" (15.5 mm) height |
| Output Connector | 3-pin XLRM-type on cable |
