- Asymmetric waveguides for enhanced pattern control
- Low resonance fibreglass composite construction
- Integrated flying and mounting system
- Optional floor stand or flying bracket
- Frequency Response: 120 Hz - 20 kHz ±3 dB
- Efficiency1: LF: 107 dB 1W/1m, HMF: 110 dB 1W/1m
- Crossover Points: LF: 120 Hz and 500 Hz, HMF: 500 Hz - Passive 1.4 kHz
- Nominal Impedance: LF: 8 Ω, HMF: 8 Ω
- Power Handling2: LF: 700 W AES, MHF: 250 W AES
- Maximum Output3: 135 dB cont, 141 dB peak
- Driver Configuration: 1 x 15” LF, 1 x 8” MF, 1 x 1.5” HF compression driver
- Dispersion: 90°H x 60°V (asymmetrical)
- Connectors: 2 x 4-pole speakON™ NL4
- Weight: 47.1 kg (103.8 lbs)
- Enclosure: Fibreglass composite
- Mounting: Integral mounting system
- Colour: Custom colours available upon request
