Operating with an outstanding frequency response of 50 Hz - 20 kHz ±3 dB, demonstrating the loudspeaker’s versatility; also making it ideal choice for the main speaker system of a small to medium sized venue, such as a nightclub, bar or lounge.
- Compact and unobtrusive appearance
- Rotatable 90° to 60°H x 60°V HF waveguide
- 15” low frequency driver
- 1” high frequency compression driver
- Frequency response: 50 Hz - 20 kHz ±3 dB
- Efficiency1: 99 dB 1W/1m
- Crossover points: 2.1 kHz passive
- Nominal impedance: 8 Ω
- Power handling2: 450 W AES
- Maximum output3: 125 dB cont, 131 dB peak
- Driver configuration: 1 x 15” LF, 1 x 1” HF compression driver
- Dispersion: 90°-40°H x 60°V rotatable
- Connectors: 1 x Phoenix with link out and 1 x speakON™ with link out
- Weight: 31 kg (68.3 lbs)
- Enclosure: 15 mm birch plywood
- Finish: Textured polyurethane
- Grille: Perforated steel with foam filter
- Rigging: Yoke bracket positions, 4 x M8 fixing points for type 80 plate, Optional top hat
1 Measured in half space 2 AES2 - 1984 compliant 3 Calculated
