- 110° horizontal dispersion
- True cylindrical wavefront
- 2 x 8” mid drivers with phase device
- 2 x 8” horn loaded low frequency drivers
- 2 x 1.4” compression drivers
- Rigging angle pre-selected before you lift the enclosures
- Ground stackable
- Frequency response: 110 Hz - 20 kHz single enclosure, 90 Hz - 20 kHz three enclosures
- Efficiency1: LF: 100 dB | MF/HF: 106 dB 1W/1m
- Nominal impedance: 2 x 16 Ω
- Power handling2: LF: 500 W AES, HMF: 500 W AES
- Maximum output3: 132 dB cont, 139 dB peak
- Driver configuration: 2 x 1.4” compression drivers, 2 x 8” mid drivers with phase device, 2 x 8” horn loaded low frequency drivers
- Dispersion: 110°H x 12°V
- Protection: Internal electronic control
- Connectors: 2 x 4-pole speakON™ NL4
- Weight: 39 kg (86 lbs)
- Enclosure: 15 mm multi-laminate plywood
- Rigging: angle pre-selected before you lift the enclosures, ground stackable
- Finish: Textured ‘TourCoat’ polyurea
- Grille: Perforated steel with foam filter
